A negative and positive pressure deviceRemoves 99.97% of fine dust and various harmful substances by applying a 4-stage filter after introducing outside air into the room. By maintaining positive pressure, harmful substances coming in from the outside are blocked and the room is automatically ventilated continuously.
- ✓
The outside air is introduced into the room through the positive and negative pressure machine.
- ✓
Purifies and discharges polluted air, viruses, and bacteria
- ✓
More than 99.97% removal at 0.3 micrometers
- ✓
Brings clean air into the room
- ✓
Maintains negative pressure to block external harmful substances and continuous indoor automatic ventilation system
- ✓
Real-time confirmation through the monitoring measurement service and app service by installing a real-time fine dust sensor system
Composition of A negative and positive pressure device
| ACT-C-MV300 | ACT-C-MV500 | ACT-C-MV800,1000 | |
|---|---|---|---|
| Power | 220V/60Hz/single-phase 145w | 220V/60Hz/single-phase 200w | 220V/60Hz/single-phase 420w |
| Air volume (the area used) | 300CMH | 500CMH | 800CMH, 1000CMH |
| Air purification efficiency | It can be removed as much as 99.97% or more based on 0.3 micrometers | ||
| Filter composition | PRE+Carbon+Medium+HEPA 4 types of filters | ||
| Product size | 959(W) x 643(D) x 335(H) | 1073(W) x 643(D) x 335(H) | 1073(W) x 948(D) x 335(H) |
| Diameter of the connecting duct | 150 | 200 | 250 |
| Filter replacement cycle | 2 years (50mmAq differential pressure) | ||
Basic functions of a negative and positive pressure device
Air volume can be adjusted in 3 stages: strong/medium/weak
Automatic ventilation and timer function
Service of filter check notification
Competitiveness of a negative and positive pressure device
| 01 | It serves to remove air pollutants and has the function of a filter cartridge to prevent dust, soot, and yellow dust. |
|---|---|
| 02 | It is suitable for a space that requires a clean room that blocks viruses and pathogens |
| 03 | By using the method of collecting filter, both functions of ventilation & air purification are satisfied. |
| 04 | Low-noise fan due to high-efficiency BLCD Motor |
| 05 | High efficiency in cleaning by applying high efficiency HEPA filter and testing the application of PM0.3 standard, which is smaller than PM2.5 of ultrafine dust in Korea |
Demanders and application organizations of a negative and positive pressure device
Animal Hospital
Infirmary
Hospital room
Postpartum care center
Nursing home
Clean room
