Air Purifying CirculatorRemoves 99.97% of fine dust and various harmful substances by applying a 4-step filter after introducing outside air into the room. By maintaining positive pressure, it blocks external harmful substances and automatically ventilates the room continuously.
- ✓
Use an air purifying circulator to introduce outside air into the room
- ✓
Blocks fine dust and various harmful substances by using a 4-stage filter
- ✓
More than 99.97% removal per 0.3 micrometer
- ✓
Brings clean air into the room
- ✓
By maintaining positive pressure, it is possible to block external harmful substances and to continuously ventilate the room automatically
- ✓
Real-time confirmation is possible with monitoring measurement service and app service through the installation of a real-time fine dust sensor system
Composition of air-purifying circulator
| ACT-C-V300 | ACT-C-V500 | ACT-C-V800,1000 | |
|---|---|---|---|
| Power | 220V/60Hz/single-phase 145w | 220V/60Hz/single-phase 200w | 220V/60Hz/single-phase 420w |
| Air volume (the area used) | 300CMH(11.7/38.5㎡) | 500CMH(19.4/64.2㎡) *based on ventilation twice per hour |
800CMH(31.1/102.7㎡) 1000CMH(38.9/128.3㎡) |
| Air purification efficiency | It can be removed as much as 99.97% or more based on 0.3 micrometers | ||
| Filter composition | PRE+Carbon+Medium+HEPA 4 types of filters | ||
| Product size | 959(W) x 643(D) x 335(H) | 1073(W) x 643(D) x 335(H) | 1073(W) x 948(D) x 335(H) |
| Diameter of the connecting duct | 150 x 2 | 200 x 2 | 250 x 2 |
| Filter replacement cycle | 2 years (50mmAq differential pressure) | ||
Basic function of air purifying circulator
3-stage control of high/medium/weak air volume
Function of automatic ventilation and timer
Filter check notification service
Bypass function
Competitiveness of air-purifying circulator
| 01 | 30~40% ventilation function |
|---|---|
| 02 | By applying a high-efficiency HEPA filter, the efficiency related to cleanliness is high in the application test with PM0.3 smaller than PM2.5 of domestic standard ultrafine dust |
| 03 | It is possible to check the cleanliness of indoor air quality in real-time through high-accuracy sensors and monitoring |
| 04 | The collection filter method is applied to satisfy both functions of ventilation and air purification. |
| 05 | Oxygen deficiency and CO₂ concentration can be reduced, and radon gas emission is possible |
Demanders and application organizations of air purifying circulators
Hospital
Office
School
Bank
Public institutions
Multi-use facility
Hospital
Office
School
Bank
Public institutions
Multi-use facility
